De Dietrich Virtuens 25/30 MI condenserende gaswandketel voor verwarming en instante SWW

De Dietrich Virtuens 25/30 MI condensing gas wall-mounted boiler for heating and instante SWW

Name: De Dietrich Virtuens 25/30 MI condensing gas wall-mounted boiler for heating and instante SWW
Brand: De Dietrich
SKU: VM-20069357
Price: 3157.05 EUR
Availability: InStock

Reference VM-20069357 EAN code 8022945043982

€3.157,05 €2.609,13

incl. 21% VAT · €2.609,13 excl. VAT excl. 21% VAT · €3.157,05 incl. VAT

In stock · ships in 3-6 working days

Estimated delivery 3-6 working days after ordering

Total €3.157,05 €2.609,13

Quick pick

Quote for pros

Free delivery in Belgium from €65 excl. VAT
14-day right of return
2 year manufacturer warranty
VAT invoice with every order

Secure payment

Not sure this is the right part?

+32 2 886 10 49

Mon-Fri 8am-5pm

Send us your material list

Specifications

Reference: VM-20069357
Material, heat exchanger: Stainless steel
Closed finish: Yes
Open and closed finish: Yes
Condensation: Yes
Nominal output 50-30 °C: 27.2kW
Nominal useful output 80-60 °C: 25kW
Nominal load, higher value: 28.5kW
Nominal load, lower value: 25.7kW
Suitable for low-calorific natural gas: Automatic settable
Suitable for high-calorific natural gas: Automatic settable
Suitable for propane: Automatic settable
Suitable for butane: Automatic settable
Suitable for methane: Automatic settable
Suitable for liquefied petroleum gas (LPG): Automatic settable
Suitable for hydrogen: Automatic settable
Hydrogen percentage: 20%
Adjustable heating power: Yes
Ignition flame: No
Conversion kit available: No
On/off control signal: Yes
High/low control signal: No
OpenTherm control signal: Yes
Control signal 0-10 V: Yes
High/low burner regulation: No
Modulated burner control: Yes
Maximum temperature of the inlet water (operating temperature): 80°C
Minimum setback temperature: 20°C
Minimum working pressure: 0.5bar
Max. operating pressure: 3bar
Efficiency: 98.7%
Energy saver included: Yes
Maximum upstream gas pressure: 30mbar
Minimum upstream gas pressure: 20mbar
Water side resistance at dT 20 °C: 24.5kPa
Second outlet connection: No
Nominal power, sanitary water: 30kW
Nominal power low value, sanitary water: 34.4kW
Nominal power high value, sanitary water: 31kW
Flow rate ECS according to EN13203-1: 14.3l/min
Faucet base: 2l/min
Available hot water network volume at 60 °C: 8.6l/min
Rated voltage: 196V
Frequency: 50 Hz
Sanitary hot water reservoir: 1l
Integrated distribution/filling valve: No
Integrated pump switch: Yes
Built-in manometer: Yes
Integrated ambient conditions controller: Yes
Integrated expansion vessel: No
Integrated overpressure valve: Yes
Built-in inlet combination: No
Height: 765mm
Depth: 330mm
Width: 450mm
Supply connection: Parallel male gas thread (BSPP)
Nominal diameter of the supply: 3/4 inch (20)
Diameter outside of the inlet pipe: 26.44mm
Return connection: Parallel male gas thread (BSPP)
Nominal diameter return: 3/4 inch (20)
Diameter outside of the return pipe: 26.44mm
Connection, fuel: Parallel male gas thread (BSPP)
Nominal inner diameter fuel: 3/4 inch (20)
Diameter outside of fuel pipe: 26.44mm
Connection, air duct: Insertion piece
Nominal diameter of the air duct: 125mm
Connection, flue gas discharge: Insertion piece
Nominal diameter of the duct, flue gas discharge: 80mm
Cold drinking water connection: Parallel male gas thread (BSPP)
Diameter outside of cold potable water pipe: 20.955mm
Nominal diameter, cold drinking water: 1/2 inch (15)
Hot water connection: Parallel male gas thread (BSPP)
Nominal diameter of the hot water connection: 1/2 inch (15)
Condensate connection: Other
Diameter of condensate thread: DN 20
Diameter outside of condensate pipe: 20mm
Relaxation connection: Other
SEER (Seasonal Energy Efficiency Ratio) in cold conditions: 98.7
SEER (Seasonal Energy Efficiency Ratio) in standard conditions: 94
SEER (Seasonal Energy Efficiency Ratio) in hot conditions: 87.8
Energy efficiency of hot water: 87%
Capacity profile: XL
Useful heat emission at nominal heat in high temperature operation (P4): 25kW
Useful efficiency at nominal heat in high-temperature operation (n4): 87.8%
Energy efficiency of room heating: 94%
Additional full-load electricity consumption (Elmax): 0.035kW
Heat loss in standby (Pstby): 0.04kW
Additional standby electricity consumption (Psb): 0.004kW
Gas label HR: No
Gaskeur NZ: No
EAN code: 8022945043982

Key features

Height: 765mm
Material, heat exchanger: Stainless steel
Closed finish: Yes
Open and closed finish: Yes
Condensation: Yes

About this product

De Dietrich. VIRTUENS MI. boilers wall-mountedes gaz à condensation for heating et production d’hot water sanitary micro-accumulée. Faibles émissions polluantes. Corps de chauffe compacte en acier stainless steelydable. Module air/gaz integrant le bruleur gas modulant de 10 à 100% et le système electronique de gestion automatic de la combustion. check valve anti-retour fumées inteegré. Éclairage LED inteegré. Fourni with une plaque de montage with taps prémonteee et kit de remplissage automatic inteegré approuvé per Belgaqua. boiler entièrement équipée with pump de heating modulante, vase d’expansion 8 l, échangeur à plaques stainless steel for la production d’ecs, purgeur d’air automatic, soupape de sécuritee 3 bar et capteur de pression digital. Tableau de commande DIEMATIC Evolution, for la commande de 1, 2 ou 3 circuits CV. Sonde exteerieure incluse. ErP Ready.
